Sunmi NS021 2D Handheld Barcode Scanner
|
|
|
|---|---|
| Field of view angle |
horizontal 45°，vertical 34° |
| Sensor | CMOS, 640×480 px |
| OS | Windows/Android/Linux |
| Reading Depth of Field |
EAN13（13mil）55mm-300mm QR CODE（15mil）35mm-190mm |
| Lighting | White LED |
| Dimensions | 16cm×9.5cm×7.1cm |
| Communication interface |
USB 2.0 TypeA male connector |
| Focusing | Red light LED 625nm |
| Barcode Sensitivity |
Inclined ±50° / Rotary 360° / Deflected ±50° |
| Symbol Contrast |
≥30% |
| Prompt method |
Buzzer, vibrator LED prompt |
| Environment | Operating temperature：-10℃~50℃ Storage temperature：-40℃~+70℃ Relative humidity：5%~95%(no condensation) Electrostatic protection：±8kV(direct discharge) ±15kV(air discharge) Drop height：1.2meters |
| Symbology | 1D：Code128, UCC/EAN-128, AIM128, EAN-8, EAN-13, ISBN/ISSN, UPC-E, UPC-A, Interleaved 2 of 5, ITF-6, ITF-4, Matrix 2 of 5, Industrial 25, Standard 25, Code39, Codabar, Code 93, Code 11, Plessey, MSI-Plessey, RSS-14、 RSS-Limited、RSS-Expand 2D：PDF417，QR Code，Data Matrix |
