HDMI Video Capture 4K Ultra HD
- HDMI signal grabber directly to your computer via USB 3.0 port
- Compatible with Windows, Mac OS X and Linux
- Maximum input signal resolution: 4K 60Hz, HDR10 support
- Maximum resolution of the captured signal: Full HD 60Hz
- Inputs: 1x HDMI, 1x 3.5mm audio minijack
- Outputs: 1x HDMI loop, 1x USB 3.0, 1x 3.5mm audio minijack
- Powered via USB 3.0 port - no external power source required
- Conforms to UVC and UAC standards .
- Grabber plug'n'play, does not require installation of external drivers,
- Perfect for capturing, streaming or conducting live broadcasts, video conferences, trainings, webinars or video calls using the most popular applications and services.
CE-CVHU is a video grabber that accepts HDMI 2.0 signals with a maximum resolution of 4K2K @ 60Hz (4: 4: 4) from HDR10 to a computer with Windows 7 / 8.1 / 10, Mac or Linux OS and captures in resolutions up to Full HD (1080p60) through the USB 3.0 connector, ensuring fast transmission.
It has a 3.5mm minijack audio microphone input, allowing you to select the audio captured from either the analog input or the HDMI input. In addition, the device has an HDMI 2.0 preview output and an audio DE embedder function (3.5mm line audio output). The HDMI 2.0a input accepts input resolutions up to 4K2K @ 60, while the preview output max. up to 1920 × 1080 @ 60. The material is captured in full HD 60Hz quality.
CE-CVHU is compatible with the vast majority of popular capture programs, including OBS, VLC and XSplit.
It is the perfect streaming grabber for YouTube, Facebook, Ustream and Twitch coverage
Grabber is detected by many platforms and applications for video conferencing, training, webinars and video calls as a webcam. Therefore, it is a great choice for direct use (without intermediaries) with Skype, Zoom, Microsoft Teams, Click meeting, WebEx, Google Hangouts, Google Meet or other services and applications.
Conforms to UVC and UAC standards.
Main features of CE-CVHU:
- Capturing video and audio from HDMI sources via USB 3.0 / 2.0
- Acceptance of signals with resolutions up to 4K @ 60Hz 4: 4: 4, 1080 @ 120Hz and graphic resolutions up to 2560 × 1600 @ 60Hz
- HDR10 support
- MJPEG compression
- Has an HDMI loop output
- Capture at maximum resolution up to 1080p at 60 frames per second
- Cooperation with Windows, Linux, Mac OS X computers
- Confirmed compatibility with many capture applications: OBS, VLC, XSplit, VMix, Potplayer, QuickTime and others
- The perfect grabber for streaming as well as for broadcasting and live broadcasting on YouTube, Facebook, Ustream and Twitch
- Perfect for video conferences, trainings, webinars or video calls via Skype, Zoom, Microsoft Teams, Clickmeeting, Webex, Google Hangouts, Google Meet or other services and applications
- Has 1x 3.5mm stereo analog input (audio embedder)
- Has 1x 3.5mm stereo analog output (audio dembedder function with HDMI)
- The grabber supports pass-through 4K2K @ 60Hz on the HDMI preview output
- The grabber supports HDMI input signals with HDCP 1.4 / 2.2
- No drivers required - detected by capture or streaming software as a "webcam"
- Conforms to UVC and UAC standards
- Powered via USB 3.0 port - no external power source required
Technical data
- Inputs: HDMI type A, analog audio 3.5mm mini jack
- Outputs: HDMI type A, USB 3.0 type A, analog audio 3.5mm minijack
- Supported HDMI input resolutions: up to 4K @ 60Hz 4: 4: 4 HDR10
- Supported HDMI output resolutions: up to 4K @ 60Hz 4: 4: 4 HDR10
- Capture up to Full HD 1080p @ 60Hz
- Compression: MJPEG
- USB output color space: YUV2, RGB
- HDMI audio format: LPCM 7.1 audio, Dolby Atmos®, Dolby® TrueHD, Dolby Digital® Plus, DTS: X ™, and DTS-HD® Master Audio ™ pass-through
- Mic input audio format: PCM 2.0
- Headphone output audio format: PCM 2.0
- Supported operating systems: Windows, Mac OS X, Linux
- Working temperature: -5 to + 55 ° C
- Dimensions [width W x H x D]: 102mm x 13mm x 61mm
- Weight: 75g
